Aluminium Structural Framing – Air Supply Elements

Pneumatic Port G1/2

Material:

  • Port: die-cast zinc
  • Hardware: zinc-plated steel

Features:

  • Allows installation of a G1/2″ pneumatic port for compressed air tools on 45x90H, 45x180H, 90×90, and 90×180 profiles
  • Can be mounted anywhere along length of profile
  • Can be used with compressed air up to 8 bar (≅120 psi)
  • Requires drilling a 10mm hole into center channel of profile
  • Includes port, gasket, and mounting hardware
  • May be used with G1/2″ to G1/4″ reducing nipples, as well as screw plugs for unused ports (order separately below)

Pneumatic Port G3/8

Material:

  • Port: die-cast zinc
  • Hardware: zinc-plated steel

Features:

  • Allows installation of a G3/8″ pneumatic port along the center channel of most standard profiles with 10mm T-slots
  • Can be used with compressed air up to 8 bar (≅120 psi)
  • Can be mounted anywhere along length of profile
  • Includes port, gasket, and mounting hardware

45mm Pneumatic End-to-End Kit

Material:

  • End plates: die-cast aluminum
  • Hardware: zinc-plated steel

Features:

  • Connects two 45×45 profiles together end-to-end to create an uninterrupted pneumatic duct via the center channel
  • Can be used with compressed air up to 8 bar (≅120 psi)
  • Maximum torque on profile connection is 120 Nm
  • Includes all mounting hardware, seals, and two hollow M12 screws

45mm Pneumatic T-Junction Kit

Material:

  • End plate: die-cast aluminum
  • Hardware: zinc-plated steel

Features:

  • Connects two 45×45 profiles together at right angles to create a pneumatic duct via the center channel
  • Can be used with compressed air up to 8 bar (≅120 psi)
  • Maximum torque on profile connection is 120 Nm
  • Can be installed anywhere along length of profile
  • Includes all mounting hardware, seals, and two hollow M12 screws

Air Gaskets

Material:

  • 45x90H air gaskets: PUR
  • 45x180H, 90×90, and 90×180 air gaskets: NBR

Features:

  • Provide a seal between connecting ends of 45×90, 45x90H, 45x180H, 90×90, and 90×180 profiles to create a continuous linear channel
  • Allows use of center channel to create an air duct for compressed air up to 8 bar (≅120 psi)
  • 45x90H, and 45x180H require two end-to-end 45mm bolt connector kits (order D separately below)
  • 90×90 and 90×180 require four universal bolt connector kits (order E separately below)

cap6

Multi-Port End Seal Kits for 45×90, 45x80H, and 90×90 Profiles

Material:

  • End plate: die-cast aluminum
  • Gaskets: 45×90–PUR; 45x180H and 90×90–NBR

Features:

  • Allows use of center channels to be used as air ducts for compressed air up to 8 bar (≅120 psi)
  • Center bores of profiles can also be used to carry compressed air by replacing the M12 screws with M12-to-G1/4″ fittings (sold separately, details on page 8-1)
  • 45x90H and 45×180 feature G 1/4″ ports; 90×90 features a G3/4″ port
  • Includes end plate, gaskets, plugs, and all necessary mounting hardware
  • Additional G1/2″ plugs and seals, as well as G1/2″-to-G1/4″ reducer nipples, are available separately
